| Model Number: | mds-dh-sp-100 |
| MOQ: | 1 |
| Price: | 326.5 usd |
| Payment Terms: | T/T |
| Supply Ability: | 1000 |
The MDS-DH-SP-100 is a premium spindle drive unit engineered for demanding CNC machining and industrial automation applications. As part of the advanced MDS-DH Series of AC servo drives, this spindle amplifier delivers exceptional motor control performance, high torque output, and reliable operation in the most challenging industrial environments.
With a rated output power of approximately 15kW and a peak nominal current of 100A, this spindle drive is designed to power high-performance spindle motors in machining centers, milling machines, turning centers, and heavy automation platforms. The unit utilizes a sine wave PWM control strategy for enhanced motor drive efficiency and smooth operation.
| Part Number | MDS-DH-SP-100 | MDSDHSP100 |
|---|---|
| Product Type | Spindle Drive Unit / Spindle Amplifier |
| Series | MDS-DH Series |
| Category | AC Servo Drive / Industrial Automation Component |
| Condition | Brand New |
| Output Power | 15kW |
|---|---|
| Peak Current | 100A |
| Input Voltage | 380-480V AC, 513-648V DC |
| Frequency | 50/60Hz |
| Rated Output | 30A |
| Control Method | Sine Wave PWM Vector Control |
| Cooling | IP20 Forced Air Cooling |
| Operating Temperature | 0-55°C |
| Communication | SSCNETⅢ/H CC-Link IE Field Optical Communication |
| Features | Regenerative Braking |
